All right, so let's. Let's dive into something I think we all kind of take for granted every day. We use it, but we don't really think about the process of making it. And that's plastic.
Yeah.
I mean, plastic is in everything.
It is.
It's in our phones, it's in our cars, it's even in the packaging that our food comes in.
Right.
But have you ever thought about what makes injection molded products so strong?
Yeah, it's a fascinating process. Yeah. You know, it's a lot more than just melting plastic and just pouring it into a mold.
Right.
There's a lot of factors at play that determine the strength and durability of the final product.
That's what we're looking into today. We're going to deep dive into this world of injection molding, and we're going to talk about the different parameters that we can tweak that create these really tough plastic products.
Right.
And we've got a stack of research here that we're going to kind of pull from.
Excellent.
So sounds good. Let's jump right into it. So it's really interesting to me how even small adjustments to this process can have a huge impact on the final product.
They can.
And we're talking about things like injection pressure, the speed at which it's injected, cooling times, mold temperatures. All these things play a factor. So let's just start with injection pressure.
Okay.
What is that all about?
So injection pressure is essentially the force that pushes that molten plastic into that mold.
Okay.
And so too little pressure and you're going to have a situation where maybe it doesn't fill properly.
Right.
But then too much pressure, you're going to get internal stress, and that can actually weaken the product.
Oh, so it's like the Goldilocks principle.
Yeah. It's about getting it just right.
You got to find the right amount.
Yeah. You don't want it too hot, you don't want it too cold.
Exactly.
I want it just.
And so when we're talking about too much pressure, I'm imagining that creating internal stresses. It's like forcing something into a space where it doesn't really want to go.
Exactly. And if you think about it, you're.
Pushing that molten plastic with immense pressure into this confined space. So if it's too high, it's going to cause weaknesses in that part, and it might not be immediately apparent, but it can lead to failures down the line.
Right. So we're talking long term durability here, something that you might not see in the short term. But over time, that stress is just going to.
Yeah. It's going to cause cracks, it's going.
To cause breaks, it's going to cause problems.
Yeah. And it's going to be weaker than it should have been.
Okay. So it's all about finding that balance, finding that sweet spot.
That sweet spot.
That's right.
Okay. And I think. I think one of the research papers talked about polyamide as a good example of this.
Yes. So with polyamide, which is a very common engineering plastic, they found that if you increase the injection pressure from like, the normal 70-80 MPa to, like, 90 to 100.
Wow.
That really improved the impact resistance, particularly in applications where it's under high stress.
Okay. So for our listeners who might not know what a megapascal is, can you kind of break down what that unit of measurement is?
So a megapascal is basically just a unit of pressure.
Okay.
It's commonly used in engineering to describe, you know, the force acting on a certain area.
Okay.
So in this case, you know, higher megapascals, we're talking about more pressure, more force pushing that polymide into the molecule. So it ensures that the material is packed in nice and tight.
Right.
Reducing the risk of any kind of vords.
Okay.
And improving that overall strength.
So we're talking injection pressure.
Yes.
And it's about force.
Yes.
But we also have to think about the speed at which it's injected.
That's right.
So how does speed play into this?
So injection speed is all about how quickly that molten plastic enters the mold.
Okay.
And it's important because if it's too slow.
Yeah.
The material might start to cool and.
Solidify before it even gets in there.
Before it's fully filled.
Right.
And that's going to lead to inconsistencies and weaknesses in the final product.
Yeah, I can imagine.
But if it's too fast, then that can also create its own challenges as well.
So it's like pouring cake batter into a pan.
Yeah.
If you pour it too slow, it's not going to fill evenly.
Right.
And if you pour too fast, you're going to have a mess.
Exactly. You're going to have it splattering everywhere, and it's not going to bake properly.
Right.
So it's similar with plastic injection.
Okay.
You want to make sure that speed is just right.
So we're finding that balance again.
Exactly. It's all about balance.
Okay. And I think there was another study that talked about electronic casings.
Yes. So for things like electronic casings, which are Often very thin walled.
Yeah.
They found that increasing the injection speed from, like, the standard 30 to 40 millimeters per second.
Okay.
To 40 to 50 millimeters per second.
A slight increase.
A slight increase. Yeah. And that actually resulted in a much more uniform fill.
Wow.
And a stronger part with fewer defects.
Okay. So we're talking tiny adjustments.
Tiny adjustments. Yeah. But they can make a big difference.
Yeah, make a huge difference. So we've talked about pressure, We've talked about speed.
Right.
Now, what about these packaging parameters that we talked about before?
Yeah. So once you get that plastic into the mold.
Right.
Then those packaging parameters come into play.
Okay.
And they're really important for the final stages of that molding process because they ensure that the plastic solidifies properly.
Okay. So if pressure and speed are about getting it into the mold.
Yes.
This is about what happens once it's in there.
That's right.
Okay.
These parameters are all about controlling the way that that plastic hardens and becomes a solid product.
And I'm imagining holding pressure comes into play here.
Yeah. So holding pressure is like giving the plastic a little hug.
Okay.
Make sure it's nice and dense.
Got it.
So after the mold is full, we apply that holding pressure, and it just compacts the material and makes sure that it's well formed.
Right. And holding time would be the length of that hug.
Exactly the length of the hug.
Okay. So if it's a thicker product, you're going to want to hold that hug for a little bit longer.
That's right. Give it a longer squeeze. Make sure it's really setting properly.
I see.
Yeah. And the research suggests that, you know, for thicker products, you might want to hold that pressure for, like, eight to 12 seconds.
Okay.
Just to make sure that everything's cooling evenly and you don't have any warping or problems with structural integrity.
So holding pressure, holding time, that's all part of that packaging.
Yep, that's all part of it.
Okay. Now we also have mold temperature.
Right.
Now, this seems pretty intuitive.
Yeah.
Heat affects how things cool and solidify.
Exactly.
So how does the mold temperature play into the strength of plastic?
So mold temperature is really all about controlling how that plastic cools and solidifies. And in particular, it influences the crystallization process for plastics that have a crystalline structure. So you can think about it like tempering chocolate.
Yeah.
Different temperatures are going to create different textures.
Right. So it's about choosing the right mold temperature for the type of plastic that you're using.
Exactly. You've got to make sure those temperatures are compatible with each other.
Okay. And I think polypropylene was one of the examples that was given in the research.
Yeah. So polypropylene is commonly used in a ton of different products, like food containers and car parts.
Yeah.
And they found that a higher mold temperature, like around 50 to 60 degrees Celsius.
Okay.
That actually helps to create larger, more uniform crystals.
So the crystals are what give it the strength.
Exactly. So those larger crystals create a stronger, more rigid material.
I see.
Which is important for products that need to withstand a lot of force or stress.
Okay, so we've got injection pressure, speed, holding time, and temperature.
Right.
Now. What about cooling time? How does that come into play?
Cooling time is essential because it allows that molded part to harden evenly and properly.
Okay.
So if we rush the cooling process.
Yeah.
We risk warping dimensional inaccuracies and a weaker product overall.
So it's like if you take a cake out of the oven too soon.
Exactly.
It's not going to be set. It's going to be a mess.
It's going to collapse in the middle. You're going to have a soggy mess.
Yeah. So we got to give it the time to cool.
Give it time. Let it cool down.
All right, so we've covered a lot of ground here.
We have.
I've got injection pressure, injection speed, holding pressure, holding pressure, holding time, mold temperature, mold temperature, cooling time.
That's right.
It's like a carefully choreographed dance.
It is. It's a delicate balance of all these.
Factors, and all of these things lead to a strong final product.
Exactly. And it's what makes injection molding so fascinating.
This is amazing. I never knew how much went into making plastic.
There's a lot to it.
I'm sure we've only scratched the surface here.
Yeah. We've only just begun to explore the intricacies.
I'm excited to dive deeper.
Me, too. Yeah. It really is amazing.
It's amazing. And you think about how many products we use every single day.
Yeah.
And they've all gone through this process.
Yeah.
And it all comes down to, you know, the. The things that we're talking about getting those parameters right to create a strong product.
That's right.
And it's wild. You know, we were talking about ejection speed and pressure.
Yeah.
And it's not as simple as just cranking those up to the max.
No, not at all.
You can't just, you know, go 100 miles an hour and as much pressure as possible.
Right. It's about finding that balance.
Right.
That sweet spot where you're getting that smooth, even Flow.
Right.
Without causing any problems.
And so I like the analogy that you used about a garden hose.
Oh, yeah. Think about it.
Yeah. Tell me more.
If you turn that water pressure up way too high.
Yeah.
The water's going to blast out.
It's going to damage your plants.
Yeah. It's going to cause damage.
Right.
But then if you have the pressure too low.
Yeah.
The water is just going to trickle out and it's not going to reach where it needs to go.
Right.
So injection speed is similar.
Okay.
You need enough pressure to make sure it fills the mold.
Right.
But not so much that it causes turbulence and defects.
Right. And I remember there was a study about that.
Oh, yeah. There's a lot of research on this.
Where they looked at.
Yeah.
The speed and the fine tuning of it.
Yeah. They looked at electronic casings specifically, because those are often very thin walled and have really complex designs.
Right. So it's a good test case.
Yeah. And they found that a slight increase in injection speed, along with careful adjustment of the pressure led to a much better product.
Yeah.
And they had to be really precise, because if it was too fast or too slow, you get all sorts of problems.
Right.
Like short shots where the mold doesn't fill all the way, or flash where excess material squeezes out.
Yeah. It's interesting how fine tuned that is.
It is. Yeah.
I mean, we're talking minute adjustments.
Yeah. Millimeters per second make a difference.
Wow. And that's amazing to me.
It is. It's a very precise process.
So. Okay, so we're talking injection speed, ejection pressure, and then we're talking.
And then we've got those packaging parameters.
Right. And that's after it's in the mold.
Right. Once the mold is full.
Right.
That's when those packaging parameters come into play.
Okay.
And we talked about them a little bit earlier.
Right. Giving it a hug.
Giving it a hug.
Yeah. And so can you remind me, why is that hug so important for the strength of the final product?
Well, think about building a sand castle.
Okay.
If you just loosely pack the sand.
Right. It's going to fall apart.
It's going to be weak and crumbly. Yeah. But if you pack it down nice and tight.
Right.
It's going to hold its shape.
Right.
So holding pressure is kind of like that for plastic. It squeezes out any air pockets, makes the material nice and dense, prevents things like sink marks, where are sink parts. So sink marks are those little depressions.
Oh, yeah. I've seen those.
Yeah. You see them sometimes on plastic products.
Yeah.
And those Happen when the material shrinks as it cools.
Right.
And without enough holding pressure, you get those little dents.
Okay. So the holding pressure prevents that.
Yes. And it helps to prevent that.
So we're talking about sink marks. Holding pressure. Holding time. Yes. Especially for thicker products.
Yeah. Thicker products need more time to cool down and solidify.
Yeah.
So if you release that holding pressure too soon.
Yeah.
You can get internal voids and warping.
Right.
Because the inner layers might still be molten while the outer layers are solid. So you want to give it enough time.
So it's all about even cooling.
Exactly.
And giving it that time to solidify.
That's right.
Okay, so we're talking holding pressure, holding time, and then mold temperature. Yeah, we talked about that before. How does that affect the crystallization process?
Okay, so you know how water turns into ice?
Yeah.
When water freezes, its molecules arrange themselves into a crystal structure, and that's what makes it solid.
Right.
So some plastics behave in a similar way.
Really?
Yeah. It's called semicrystalline polymers.
Okay.
And polypropylene is a good example. And just like with water freezing, the rate and temperature at which plastic cools affects the size and arrangement of those crystals.
So we can control the cooling process.
Yes.
And that affects how the crystals form.
Exactly.
Oh, wow.
Yeah. So mold temperature is really important for that. A higher mold temperature usually leads to slower cooling, which gives those polymer chains more time to arrange themselves and form those larger, more organized crystals.
So it's about giving it the time to align.
Yeah, give it time. Let it do its thing.
I see.
And that makes the plastic stronger and stiffer.
So for polypropylene, we want a higher mold temperature generally.
Yes. There was a study that showed that increasing the mold temperature from 40 degrees Celsius to 60 degrees Celsius made the polypropylene much stronger.
Wow. So we're talking a significant difference.
Yeah, Significant difference in strength. Yeah. It was able to withstand a lot more force before it broke.
And so that's for crystalline structures.
Yes.
So what about the plastics that don't form those crystal structures?
Yeah. Those are called amorphous polymers.
Okay. And they don't have that kind of ordered structure.
Right. They're more random.
Okay.
Think of like a rubber band. It's flexible and doesn't have that rigid crystalline structure.
Right.
So mold temperature is still important for those.
Okay.
But it doesn't affect the strength in the same way.
Right.
So for those polymers, other factors like molecular weight and chain entanglement are more important for determining their strength.
So It's a different process for those.
Yeah, it's a bit different, but cooling.
Time is still important.
Cooling time is always important, no matter what kind of plastic you're using.
Yeah.
Cooling time allows the part to stabilize.
Right.
Release any residual stress.
Okay.
Prevents warping and all those problems.
So it's important even after it comes out of the mold.
That's right.
Oh, really?
Yeah. Because the internal temperature of the part might still be higher than the surrounding environment.
Oh, so it's still cooling even after it's out.
Exactly.
Oh, wow.
So you have to allow for that post mold cooling.
I see.
Especially for thicker parts or parts with.
Complex shapes, just to make sure everything reaches a stable state.
Okay. So we've talked about. We've talked about a lot.
A lot.
Injection speed, pressure, holding parameters, hold temperature, cooling time.
Cooling time.
It's a lot to keep track of.
It is. It's like an orchestra.
It is. It's a beautiful analogy.
Yeah.
All these different elements working together to create this final product.
Yeah. And we've only scratched the surface.
Yeah. There's so much more we could talk about.
I know. I'm fascinated already.
And me too.
And I think it's interesting to think about how this changes our perspective on these products that we use every day.
Yeah. Because we take them for granted.
We really do.
We don't think about all the science and engineering that goes into making them.
So next time you pick up that water bottle.
Yeah.
Think about all the work, all the steps, all the delicate balance that went into making it.
Absolutely. Yeah. It's amazing how versatile it is.
It is. And it's amazing how strong some of these plastic products are. You know, I'm thinking about, like, protective gear and airplane parts.
Yeah. High performance applications.
Yeah. What makes them so different from the, you know, the plastic that I use to wrap up my leftovers.
Well, one way to make those super strong plastics is to reinforce them with other materials.
Okay.
It's kind of like adding steel rods to concrete.
So you're giving it a backbone.
Exactly. You're giving it that extra support.
Okay.
And it can dramatically increase the strength and stiffness.
So what kind of materials are we talking about?
Well, you can use things like glass fibers.
Okay.
Which are pretty common. Yeah. They're relatively inexpensive.
Right.
And they offer a good balance of strength and stiffness.
Okay.
Or you can use carbon fibers.
Oh, yeah. Carbon fiber.
Those are really strong.
I know. They use those in race cars and stuff.
Exactly. They're super lightweight, too.
Yeah.
So they're great for applications where wheat is really important. I see, like in aerospace or sporting goods.
Okay. So glass fiber, carbon fiber, and then there's even nanomaterial. Nanomaterials. What are those?
So nanomaterials are these tiny, tiny particles.
Okay.
That have really unique properties.
Okay.
And when you add them to plastic.
Yeah.
You can change the properties in some really interesting ways.
So we're getting really high tech here.
We are. Yeah.
We're talking about manipulating things at a molecular level.
Exactly.
So not just new materials.
Right.
Are there new innovations in the injection molding process itself?
Oh, yeah, absolutely.
That are making things stronger.
So mold design and manufacturing has come a long way with technologies like 3D printing.
Yeah.
We can create these incredibly detailed and precise molds.
Okay.
And that allows for more complex parts with thinner walls without sacrificing strength.
So the mold is the key.
The mold is essential. Yeah, yeah. It's the blueprint for the final product. So if you have a really good mold, you make a really good product product.
And we've got these new machines too.
Oh, yeah. The injection molding machines themselves are getting more sophisticated all the time. They've got better controls, sensors, feedback mechanisms.
Okay.
So you can really fine tune the process.
So it's all about precision and control.
Yeah, it's all about getting it just right.
And it's amazing how, you know, we're able to create these super strong products.
Right.
But we also have to think about the environment.
Yeah, that's a really important point.
Yeah.
You know, plastic is durable. It lasts a long time.
That's good and bad.
Yeah, that's good and bad.
Yeah.
Because it can contribute to plastic waste.
So how is the industry addressing this problem?
Well, there's a lot of focus on sustainability these days.
Okay, good.
One thing is using recycled plastics.
Okay, so instead of creating new plastic, we're reusing old plastic.
Exactly. So that's reduces the demand for virgin materials.
Yeah.
And it keeps plastic out of landfills.
So it's like a circular economy.
Yeah, exactly.
We're reusing things over and over again.
It's a much more sustainable approach.
And what about these bio based polymers I've heard about?
Oh yeah, bioplastics.
Yeah.
They're made from renewable resources like plants.
So we're talking about not even using fossil fuel.
Yeah. We can reduce our reliance on petroleum and create a more sustainable industry.
Are they as strong though?
That's a good question. Yeah, some of them are.
Okay.
But it's still an area of active research. But there's a lot of promise there.
So we're not Just talking about new materials. We're talking about new ways to make the process itself more sustainable.
Right.
So how do we do that?
Well, one way is to reduce energy consumption during the molding process.
Okay.
So using more efficient heating and cooling systems.
Right.
Optimizing cycle times, things like that.
So it's all about being more efficient.
Exactly. And minimizing waste.
Yeah.
Reusing materials as much as possible.
So we're looking at the whole life cycle of the product.
Yeah. From start to finish.
And how do we make it more sustainable?
That's right.
Wow. This has been an incredible deep dive. It has been the world of injection molding.
Yeah. We've learned a lot.
We have. I had no idea.
It's a fascinating process.
It is. And it's all around us.
It is. Yeah.
So I hope you know our listeners.
Yeah.
We'll look at plastic a little bit differently now.
I hope so.
And appreciate all the work that goes into making it.
Absolutely.
And think about, you know, the sustainability of it.
Yeah. Make mindful choices.
Yeah. And think about how we can create a more sustainable future.
Absolutely.
For plastic.
I agree.
Well, thank you so much for joining me on this deep dive.
It was my pleasure.
And we'll see you next
